Product Summary

The AMD Geode CS5530A-UCE companion device is designed to work in conjunction with an AMD Geode GX1 processor. Together, the Geode GX1 processor and CS5530A-UCE companion device provide a system-level solution well suited for the high performance needs of a host of devices which include digital set-top boxes and thin client devices.

Parametrics

Absolute maximum ratings: (1)Operating Case Temperature: 0 to 110 ℃ at Power Applied; (2)Storage Temperature: –65 to 150 ℃; (3)Supply Voltage: 4.0 V; (4)Voltage On Any Pin: –0.5 to 5.5 V; (5)Input Clamp Current, IIK: –0.5 to 10 mA at Power Applied; (6)Output Clamp Current, IOK: 25 mA at Power Applied.

Features

Features: (1)Designed for use with Geode GX1 processor; (2)352 PBGA (Plastic Ball Grid Array) package; (3)3.3V or 5.0V PCI bus compatible; (4)5.0V tolerant on all inputs; (5)3.3V core.

Diagrams
